1920X1080 4K Video Wall Display

Product Details

Place of Origin: CHINA

Brand Name: Smart Display

Certification: CE,FCC, ROHS ,CB

Model Number: SW-01

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: different price for different size

Packaging Details: carton+ wooden box/flight case

Delivery Time: 5-7days

Payment Terms: T/T

Supply Ability: 3000

Get Best Price
Contact Now
Specifications
Highlight:

1920X1080 4K Video Wall Display

,

500 nits lcd ad display

,

4000:1 lcd ad display

Application:
Indoor
View Angle:
178°/178°(H/V)
Panel Parameter:
RGB Vertical Stripe
Bezel:
3.5mm
Size:
55inch
Display Colors:
8bit-16.7m
Customized Service:
Yes
Brand:
Smart Display
Application:
Indoor
View Angle:
178°/178°(H/V)
Panel Parameter:
RGB Vertical Stripe
Bezel:
3.5mm
Size:
55inch
Display Colors:
8bit-16.7m
Customized Service:
Yes
Brand:
Smart Display
Description
1920X1080 4K Video Wall Display

50Hz LG LCD Video Wall Display 49Inch 3.5mm Bezel 3x3 FHD Resolution



Specification

Product size table
Panel size Bilateral seam Panel Length Panel Width Panel Thickness Panel Brand Model No.
46inch 1.7mm 1020.02mm 574.61mm 120.54mm Samsung LTI460HN15
46inch 3.5mm 1021.98mm 576.57mm 121.7mm Samsung LTI460HN11
46inch 5.5mm 1023.98mm 578.57mm 133mm Samsung LTI460HN09
49inch 1.8mm 1077.58mm 607.8mm 113.7mm LG LD490DUN-TJB2
49inch 3.5mm 1077.58mm 607.8mm 113.7mm LG LD490DUN-THC4
55inch 1.8mm 1213.5mm 684.3mm 110mm LG LD550DUN-THB8
55inch 3.5mm 1213.5mm 684.30mm 110mm Samsung LTI550HN11



PECIFICATION
Item
Model No.
VW46W/ VW55W







Panel
Parameter
Screen size
46inch / 55inch
Pixel pitch
0.53025(H)x0.53025(V) / 0.630(H)x0.630(V)
Resolution
1920X1080
Brightness
500nits
Contract Ratio
3000:1 / 4000 : 1
Viewing angle
89/89/89/89
Backlight
LED
Color depth
16.7M
Response time
<8ms
Display area
1018.08(H)×572.67(V)/ 1209.6(H)×680.4(V)
Bezel
3.5mm



interface
CVBS In / Out (BNC )
1/0
VGA In / Out
1/0
DVI In / Out
1/0
HDMI In/Out
1/0
DEBUG(USB)
1/0

control
IR remote control
Yes
RS-232 In/Out
1/2



Physical

Dimension
46 inch : 1021.98mm(W) x576.57mm(H) x121.7mm(D)

55 inch : 1213.5mm(W) x684.3mm(H) x118mm(D)
Frame color
Black
Frame material
Metal
Net weight
18.6Kg / 30Kg

Power
Power consumption
≦190W / ≦250W



Standby
<1W



Power supply
AC 100V-240V, 50/60Hz,Universal,±10%





Environment
Operating humidity
20-90% RH(no condensation)



Storage humidity
10-90% RH (no condensation)



Operating temperature
0 ~ 50° C / 32 ~ 122° F



Storage temperature
-20 ~ 60° C / -4 ~ 140° F




1920X1080 4K Video Wall Display 0

FAQ
Q1: What is the minimum order quantity?

Qty: 1 unit. Different order quantity different price. Q2: What payment methods your company accept?
Refee: It’s usually wire transfer T/T. For partner relationship, we may consider other payment terms. Q3: How long is the warranty time for your products?
We provide 1 year warranty for all of our products and supply life-time maintenance.
