Product Details
Place of Origin: China
Brand Name: Smart Display
Certification: CE,FCC, Rohs. CB
Model Number: ST-03
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Outer wooden box, middle carton, inner PE cotton
Delivery Time: 7-25
Payment Terms: TT
Supply Ability: 5000pcs/month
Name: |
HD Led Video Wall |
Tube Chip Color: |
Full Color |
Function: |
Video, Picture, Multimedia, Words, Text |
Apllication: |
Indoor |
Customized Service: |
Yes |
Brand: |
Smart Display |
Name: |
HD Led Video Wall |
Tube Chip Color: |
Full Color |
Function: |
Video, Picture, Multimedia, Words, Text |
Apllication: |
Indoor |
Customized Service: |
Yes |
Brand: |
Smart Display |
| Item | Parameter | ||||
| Module specifications | Mode | p3.91 | p3.91 | p4.81 | p4.81 |
| Module size | 250*250 | 250*250 | 250*250 | 250*250 | |
| Module pixel | 64*64 | 64*64 | 96*96 | 96*96 | |
| scan | 1/16 | 1/16 | 1/13 | 1/13 | |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | |
| LEDs | SMD1919 | SMD1919 | SMD1919 | SMD1919 | |
| Max power consumption (W/piece) | 50W | 50W | 50W | 50W | |
| Mask | have | have | have | have | |
| Main Specifications | Cabinet size | 500*500 | 500*1000 | 500*500 | 500*1000 |
| Cabinet pixel | 128*128 | 128*156 | 104*104 | 104*208 | |
| Density (dot/m2) | 65536 | 65536 | 43264 | 43264 | |
| Brightness(cd/m2) | 800-3000 | 800-3000 | 800-3000 | 800-3000 | |
| Max power consumption (W/piece) | 260W | 510W | 260W | 510W | |
| Avg power consumption (W/piece) | 90W | 170W | 100W | 170W | |
| Cabinet weight(KG) | 7KG | 13KG | 7KG | 13KG | |
| Cabinet material | Die-cast magnesium aluminum box | ||||
| IP grade | IP65 | IP65 | IP65 | IP65 | |
| Gray level | 16 bit | 16 bit | 16 bit | 16 bit | |
| Fresh rate | 3840HZ | 3840HZ | 3840HZ | 3840HZ | |
| Best viewing distance | 4M | 4M | 5M | 5M | |
| Power(V) | AC110-220V | ||||
| Working temperature | -20℃-50℃ | ||||
Product Description
>>250x250mm module, compatible with various pitches such as PH3.91/PH4.81, high selectivity
>>High-precision and ultra-practical design, 500x500/1000mm cabinet, light and easy to assemble
>>With the upper and lower arc-side locks, the angle can be adjusted to achieve arc, round and S-shaped splicing.
>>High-contrast outdoor pure black light, non-destructive refresh and grayscale. Achieve ultra-high contrast 8000:1, low brightness 800~3000cd adjustable, protect the human eye, meet indoor and outdoor application scenarios
>>Configure PWM constant current drive IC to eliminate the "caterpillar" image, low brightness and no color cast, no color block, gray scale is too smooth and no jump, no first line dark phenomenon, refresh ≥ 3840HZ, complete guarantee 16bit gray scale, Real color reproduction, high quality display
>>The flat spray mask design ensures that the entire screen plane is free of any warping, and the high-quality black protective colloid is used to perfectly realize the full-angle display of the lamp bead.
Features
1. Easy to install
2. Support front maintenance, can be curved design
3. 800-1500cd/m2 Brightness can be adjustment.
4. 5000:1 High color contrast, make the picture/Video clear and more level
5. High refresh rate (3840Hz),Using high reflesh IC, better viewing effect
