Product Details
Place of Origin: China
Brand Name: Smart Display
Certification: CE,FCC, Rohs. CB
Model Number: 43 inch wall mounted digital signage
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Outer wooden box, middle carton, inner PE cotton
Delivery Time: 7-25
Payment Terms: TT
Supply Ability: 5000pcs/month
Power Supply: |
110-220V |
Compatible HDMI Input/DVI: |
Yes |
4G/3G: |
Optional |
Usage: |
Indoor Advertising Transparent LCD Display |
Lead Time: |
7-10days |
Logo: |
Optional |
Customized Service: |
Yes |
Brand: |
Smart Display |
Power Supply: |
110-220V |
Compatible HDMI Input/DVI: |
Yes |
4G/3G: |
Optional |
Usage: |
Indoor Advertising Transparent LCD Display |
Lead Time: |
7-10days |
Logo: |
Optional |
Customized Service: |
Yes |
Brand: |
Smart Display |
Android Version Advertising Player
----------------update ads/programs by software platform remotelly
Efficient,Fast, and Convenient
1.Using A20 multimedia HD network decoder chip,based on Android 4.2.2 above OS with 1GB DDR3 memory,8gb flash ROM.More standard and open than PC based platform.
2.Support web/flash player,support two display modes while boot up:vertical and horizontal screen.
3.Support LVDS/HDMI/VGA/AV output power switch freely with 1080p point to point output. Support the printer device to output
4.Support multi-language,time setting,rolling text,clock and weather display.
5.Support any split-screen,multi-window display,different content in different windows.
6.Support remote reboot,remote shutdown,remote screenshot
7.B/S architechture, a strong background server management software support,you can set up online advertising machine parameters,create playlists issued online,real time/timing download programs from the servers and automatically play .
8.Support powerful network:network/wifi/4g
Specification:
| Name | 43inch advertising player | ||
| Panel parameter | Size | 43inch LED screen | |
| Display area | 930.24*523.26MM | ||
| Resolution | 1920*1080 | ||
| Brightness | 350cd/m*2 | ||
| Color | 16.7M | ||
| Aspect ratio | 16:9 | ||
| Response time | 6.5MS | ||
| Contrast | 4000:1 | ||
| View angle | 178°/168°(H/V) | ||
| Mainboard | 40A | ||
| System Ram | DDR3 1Gbyte | ||
| System Rom | NAND FLASH 8Gbyte | ||
| IO connectors | 1 x USB host,1 x USB OTG,1 x serial Port,1 x I2C Interface,1 x LVDS Interface ,1 x stereo Audio Out | ||
| Storage | USB/SD card | ||
| Decoding resolution | MAX 1080P | ||
| Audio | built-in HD audio 8(Realtek ALC888) audio system | ||
| Video format | MPEG1,MPEG2,MPEG4,H.264,WMV | ||
| Audio format | MP3 | ||
| Photo format | JPEG,BMP,PNG | ||
| wifi | yes | ||
| OS | android 4.4 | ||
| OSD Language | Chinese, English | ||
| Play Mode | Supports loop playback, timed playback and other multi-player mode | ||
| System Power Supply | AC 110V~240V,50/60HZ | ||
| Power cord | Yes | ||
| Case | Cold rolled steel with powder coating+ toughened glass surface | ||
| Standard operation software | free | ||
| Spare part | CD( user manual,operation software), | ||
| Environment | Operating Temperature :0°C to 40°C Storage Temperature :-20°C to 60°C Humidity:20%-80% RH at 40°C, |
||
