Product Details
Place of Origin: China
Brand Name: Smart Display
Certification: CE,FCC, Rohs. CB
Model Number: SW-01
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Outer wooden box, middle carton, inner PE cotton
Delivery Time: 7-25
Payment Terms: TT
Supply Ability: 5000pcs/month
Application: |
Indoor |
View Angle: |
178°/178°(H/V) |
Panel Parameter: |
RGB Vertical Stripe |
Bezel: |
3.5mm |
Size: |
55inch |
Display Colors: |
8bit-16.7m |
Type: |
Wall Mounted |
Resolution: |
1920*1080 /4k |
Customized Service: |
Yes |
Brand: |
Smart Display |
Application: |
Indoor |
View Angle: |
178°/178°(H/V) |
Panel Parameter: |
RGB Vertical Stripe |
Bezel: |
3.5mm |
Size: |
55inch |
Display Colors: |
8bit-16.7m |
Type: |
Wall Mounted |
Resolution: |
1920*1080 /4k |
Customized Service: |
Yes |
Brand: |
Smart Display |
video wall lcd 3x3 lcd video wall lcd video monitor video wall 4x4 seamless lcd video wall
| Product size table | ||||||
| Panel size | Bilateral seam | Panel Length | Panel Width | Panel Thickness | Panel Brand | Model No. |
| 46inch | 1.7mm | 1020.02mm | 574.61mm | 120.54mm | Samsung | LTI460HN15 |
| 46inch | 3.5mm | 1021.98mm | 576.57mm | 121.7mm | Samsung | LTI460HN11 |
| 46inch | 5.5mm | 1023.98mm | 578.57mm | 133mm | Samsung | LTI460HN09 |
| 49inch | 1.8mm | 1077.58mm | 607.8mm | 113.7mm | LG | LD490DUN-TJB2 |
| 49inch | 3.5mm | 1077.58mm | 607.8mm | 113.7mm | LG | LD490DUN-THC4 |
| 55inch | 1.8mm | 1213.5mm | 684.3mm | 110mm | LG | LD550DUN-THB8 |
| 55inch | 3.5mm | 1213.5mm | 684.30mm | 110mm | Samsung | LTI550HN11 |
| Panel | Brand | S-series | L-series | B-series |
| Panel size | 46 55 65 inch optional | 49 55 inch optional | 46 49 55 inch optional | |
| Bezel | 1.7/3.5/5.5mm | 0.88/1.8/3.5mm | 0.99/3.5mm | |
| Resolution | 1920×1080 | 1920×1080 | 1920×1080 | |
| Brightness | 500~700 cd/m² | 500~700 cd/m² | 500~700 cd/m² | |
| Constract ratio | 1200:1, 3500:1, 4000:1 | 1200:1, 1300:1, 1400:1 | 1300:1, 1400:1 | |
| Viewing angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | |
| Color | 16.7M , 72% (CIE1931) | 16.7M , 72% (CIE1931) | 16.7M , 72% (CIE1931) | |
| Backlit | WLED | WLED | WLED | |
| Frequency | 60Hz | 60Hz | 60Hz | |
| Signal interface | LVDS | LVDS | LVDS | |
| Repond time | 8ms | 8ms | 8ms | |
| Life spang | 60000 hours | 60000 hours | 60000 hours | |
| I/O | Interface | HD Interface, VGA in, DVI, BNC, Support Picture in Picture(PIP/POP/PAP) | ||
| Concatenation port | RS232-RJ45 in/out | |||
| Video | Color system | PAL/NTSC/Auto-Identify | ||
| Scene roaming | Support | |||
| Power | Power input | Build-in type, 100 ~ 240V AC, 50/60Hz | ||
| Power consumption | 180W (Max.); standby power lesss than 3w | |||
| Outlook | Shell material | Cold-rolled sheet, black | ||
| Screen position | Landscape, protrait optional | |||
| Unit demenssion | 1210.81(L)*681.52(W)*63.24+45(thickness)mm | |||
| Optional | Installation | Floor standing cabinet/bracket, and wall mounted bracket optional | ||
| Touch screen | IR touch screen optional | |||
| Splitter & matrix | 1ch in, 4/8/12/16ch out splitter optional; Matrix optional | |||
| Package | Unite Package | PE film + Foam corner protector + honeycomb box | ||
| Export Package | Export wooden box or wooden pallet | |||
| Accessories | HD cable, RJ45 cable, remote control*1, IR sensor*1 | |||
FAQ
Q: For the first order, can we place a sample order?
A: It's our honor to offer you sample.
Q: About the quality control, how will your factory guarantee it?
A:Quality is priority. We have Total Quality Management System to control LCD advertising equipment's quality. We have our own professional engineers who have rich developing and researching lcd advertising equipment experience. In the meain time our factory has gained FCC, CE, RoHS authentication, etc.
Q:What's the shipment terms and delivery time of your company?
A: The goods can be shipped by courier,by air or by sea. Depend on quantity and customer's requirement.
Q:How does your manufacturer do regarding quanlity control?
