IR Touch RK3288 Interactive Digital Kiosk 50 Scans /S Floor Standing

IR Touch RK3288 Interactive Digital Kiosk 50 Scans /S Floor Standing
Features Gallery Product Description Request A Quote
Life Time: >60,000 Hours
Brand: Lg/Samsung/Auo A Grade New Panel
CPU: I3 I5 I7
Mainboard: H81
Name: Touch Screen Kiosk
Type: Ir Touch
Customized Service: Yes
Brand: Smart Display
High Light:

RK3288 interactive digital kiosk


IR touch interactive kiosks


interactive digital kiosk 50 Scans /S

Basic Infomation
Place of Origin: China
Brand Name: Smart Display
Certification: CE,FCC, Rohs. CB
Model Number: ST-43
Payment & Shipping Terms
Packaging Details: Outer wooden box, middle carton, inner PE cotton
Delivery Time: 7-25
Payment Terms: TT
Supply Ability: 5000pcs/month
Product Description

43inch Android Floor Standing Touch Screen information kiosk touch screen



Name 43" touch screen kiosk
Panel parameter Size 43inch LED screen
Display area 941.184×529.416mm
Resolution 1920*1080
Brightness 450cd/m*2
Color 16.7M
Aspect ratio 16:9
Response time 6.5MS
Contrast 4000:1
View angle 178°/168°(H/V)
Touch screen size 43inch
type IR touch
android board RK3288
Ram 2G
wifi yes
Environment Operating Temperature :0°C to 40°C
Storage Temperature :-20°C to 60°C
Humidity:20%-80% RH at 40°C,
System Power Supply AC 110V~240V,50/60HZ
Power cord Yes
Case Cold rolled steel with powder coating+ toughened glass surface
Spare part CD( user manual,operation software)

Infrared touchscreen Panel Parameters:

Touch Max Resolution 4096×4096
Transparency > 90%, Up to 100%
Scanning Speed >50Scans/S
Response Speed <12ms
Touch Type Horizontal Multi Dot Touch Screen (Vertical way is optional)
Touch precision 0.625mm
Minimum Touch object ≥5mm
Touch Intensity Over 60,000,000 Single Point Touch
Operation System DOS, WINDOWS9X/ME/2000/XP/2003/VISTA, LINUX
perating Voltage DC 5V ±5%
Power Supply Keyboard Serial Interface
Power <1W (Current<200mA)
Communication RS-232 Interface Port, USB Port
Vandal-Proof Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break
Temperature Operating -41°C ~70°C Temperature Storage: -50°C ~85°C
Altitude 3000m
Noise None
Life Time >10 Year


IR Touch RK3288 Interactive Digital Kiosk 50 Scans /S Floor Standing 0

IR Touch RK3288 Interactive Digital Kiosk 50 Scans /S Floor Standing 1

IR Touch RK3288 Interactive Digital Kiosk 50 Scans /S Floor Standing 2



  • Outer shell is made by extra quality metal material, Color for Outer Shell Shinning Black;
  • With 3mm thickness tempered glass as protection layer against the sureface of LCD screen;
  • Full New LG or Samsung ( Made in Korea) A Grade Standard LCD Panel;
  • Support SD card or USB port at one player; it is optional for VGA Port, S-video port and port;
  • Safely locking system function to avoid flash memory card and advertising playing contents being taken away , also can be protected by password;
  • With USB update feature; support functions between the card and card copying files (such as CF card to SD card , or SD to CF card etc.); support U-copy , conveniently and quickly updating target content , more details please visit user manual;
  • Playing advertising program automatically and circular; support media format JPEG (JPG) , MP3 , AVI , MPEG1 , MPEG2 , MPEG4 , VOB and DIVX (5.0/6.0);
  • Playlists support functions , can set different folders , copy all target files to those different folders , system would default to play your target file one by one;
  • Capable of setting rolling caption on the screen, playing rolling caption in the advertisement program;
  • Build-in clock and calendar function in the system of player;
  • Support 5 groups of auto power-on/off timer, able to set those 5 groups of time one day and 7 days in one week;
  • Support shockproof and dustproof function;
  • FAQ:
    Q:How long is the warranty time for your products?
    A: Our officially promised warranty time is one whole year after delivery at best.
    Q: When will you make the delivery?
    A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
    Q:what brand of screen are you using?
    A:we are using Samsung,LG and AUO screen.
    Q: Do you have your own enclosure factory?
    A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
    Q:Do you give any discount ?
    A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
    Q:What payment methods your company accept?
    A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
